• Next-Gen Wi-Fi6 Technology — With OFDMA and MU-MIMO, RT-AX92U enables more efficient, stable, and faster transmission even when multiple devices are transmitting data at the same time.
• Flexible Wi-Fi for connected devices — RT-AX92U comes with 802.11n, ac and ax bands, which provides channels for all kinds of devices, including legacy or cutting-edge devices.
• Powerful Whole-home Wi-Fi System, the Way You Want — RT-AX92U supports ASUS AiMesh-a powerful, flexible whole-home mesh system technology. AiMesh gives you time-saving central control, and seamless roaming capability, users can use a mix of ASUS router models.
• Commercial-grade network security for family — AiProtection Pro protects all the connected devices on your home network and advanced parental controls allow you to manage the family's internet usage.

Product Segment

• AX6100 ultimate AX performance : 400 Mbps+ 867 Mbps+ 4804 Mbps

Data Rate

• 802.11n: สูงสุด 300 Mbps
• 802.11n TurboQAM: สูงสุด 400 Mbps
• 802.11ac (1024QAM): สูงสุด 867 Mbps
• WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps

Antenna

• External antenna x 4, Internal antenna X 2

Transmit/Receive

• 2.4GHz 2x2
• 5GHz-1 2x2
• 5GHz-2 4x4

Processor

• 1.8 GHz dual-core processor

Memory

• 256 MB Flash, 512 MB RAM

Boosts speed

• OFDMA (Orthogonal Frequency Division Multiple Access)
• Beamforming: standard-based and universal
• 20/40/80/160 MHz bandwidth
• * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.

Operating Frequency

• 2.4G Hz, 5 GHz-1, 5 GHz-2

Ports

• RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
• USB 2.0 x 1
• USB 3.0 x 1

Button

• WPS Button, Reset Button, Power Button

LED Indicator

• Power x 1
• Wi-Fi x 3
• WAN x 1
• LAN x 1

Power Supply

• AC Input : 110V~240V(50~60Hz)
• DC Output : 19 V with max. 1.75 A current

Package content

• RJ-45 Cable x1
• Power Adapter x1
• QSG x1
• RT-AX92U x1

Product Weight (g)

• 651

AiMesh

• AiMesh
• Primary AiMesh router
• AiMesh node

Router APP

• ASUS Router APP

Game

• Game Boost / Acceleration

Alexa

• Support Alexa skill

IFTTT

• Support IFTTT

AiProtection

• AiProtection Pro
• AiProtection
• Malicious site blocking
• Two-Way IPS
• Infected Device Prevention and Blocking

Parental Control

• Parental Control
• Parental Control Customized Internet schedule

Traffic Control

• Adaptive QoS
• Bandwidth Monitor
• Bandwidth limiter
• Maximum Bandwidth limiter rule : 32
• Traffic Monitor
• Real-time traffic monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
• Traffic Analyzer
• Traffic analysis period : Daily, Weekly, Monthly
• Website history

Wireless

• IPv6
• Wi-Fi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
• UTF-8 SSID
• Guest Network
• Maximum Guest Network rule : 2.4GHz x2, 5GHz-1 x2,5GHz-2 x4
• Guest Network Connection time limit
• Guest Network Encryption : Open system, WPA/WPA2-Personal
• WPS
• WiFi MAC address filter
• Maximum MAC filters : 64
• Wireless scheduler
• Airtime fairness
• RADIUS Client
• Universal beamforming
• Explicit beamforming

WAN

• Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
• Dual WAN
• WAN Aggregation
• 3G/4G LTE dongle
• Android tethering
• Port forwarding
• Maximum port forwarding rule : 64
• Port triggering
• Maximum port triggering rule : 32
• DMZ
• DDNS
• NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
• Let's Encrypt

LAN

• DHCP Server
• IPTV
• LAN Link Aggregation
• Manually assign IP address
• Maximum manually assign IP address rule : 64

VPN

• VPN Client L2TP
• VPN Client OVPN
• VPN Client PPTP
• VPN Server IPSec
• VPN Server OVPN
• VPN Server PPTP

USB application

• File System : FS_Tuxera_HFS+,FS_Tuxera_NTFS,FS_Tuxera_vFAT,FS_ext2,FS_ext3,FS_ext4
• 3G/4G LTE dongle
• HDD hibernation
• Safely Remove disk
• AiCloud
• Download master
• AiDisk
• Media Server
• Time Machine
• Samba Server
• FTP Server
• Shared Folder privileges

Administration

• Operating mode : Accesspoint, AiMeshnode, Mediabridge, Repeater, Router
• Operating system : ASUSWRT
• Free OS upgrade
• Firewall
• Maximum Firewall keyword filter : 64
• Maximum Firewall network service filter : 32
• Maximum Firewall URL filter : 64
• SSH
• Wake on LAN (WOL)
• Configuration backup and restore
• Diagnosis tools
• Feedback system
• System log
